ewalena::Crystal::CrystalFieldBase< dim, rank, ValueType > Class Template Reference

Base class for crystal fields of empirical moduli. More...

#include <include/ewalena/numerics/crystal_field_base.h>

Inheritance diagram for ewalena::Crystal::CrystalFieldBase< dim, rank, ValueType >:

Collaboration diagram for ewalena::Crystal::CrystalFieldBase< dim, rank, ValueType >:

List of all members.

Public Member Functions
virtual void	assign_symmetry_flags (const SymmetryFlag &symmetry_flags, const SymmetryFlag &group_flags=null)
	CrystalFieldBase (const Vector< ValueType > &moduli=Vector< ValueType >(), const SymmetryFlag &symmetry_flags=SymmetryFlag::null, const SymmetryFlag &group_flags=SymmetryFlag::null)
virtual void	distribute_moduli (const Vector< ValueType > &moduli)
SymmetryFlag	group_flags () const
unsigned int	n_components () const
Tensor< dim, rank, ValueType >	operator* () const
CrystalFieldBase< dim, rank, ValueType > &	operator= (const CrystalFieldBase< dim, rank, ValueType > &T)
SymmetryFlag	symmetry_flags () const
void	write_gnuplot (std::ostream &out) const
virtual	~CrystalFieldBase ()
Protected Member Functions
virtual void	assign_moduli (const Vector< ValueType > &moduli)
Protected Attributes
SymmetryFlag	group_flags_
Vector< ValueType >	moduli_
SymmetryFlag	symmetry_flags_

---

Detailed Description

template<int dim, int rank, typename ValueType = double>
class ewalena::Crystal::CrystalFieldBase< dim, rank, ValueType >

Base class for crystal fields of empirical moduli.

CrystalFieldBase is a base class for other classes that describe classical crystal fields that in turn describe the solid-state physics of crystal structures. Enigmatic examples of such fields are the elastic field (a fourth-order tensor) and the dielectric field (second-order) tensor.

Derived classes of the CrystalFieldBase class are normally used in application code by first assigning a crystal symmetry class and a set of moduli to the tensor base, and then let the member function distribute_moduli () automagically fill the tensor according to the rules governed by the class (or field) type and symmetry group. Schematically, this may look like:

     // Initialise an elastic tensor field and elastic moduli.
     ewalena::ElasticField elastic_field;

     // Elastic fields of cubic symmetry have exactly three
     // independent constants. This example is for cubic zinc-oxide
     // (units: GPa).
     ewalena::Vector<double> elastic_moduli = {193, 139, 96};

     // Assign symmetry flags to this elastic tensor field.
     elastic_field.assign_symmetry_flag (ewalena::SymmetryFlag::Crystal::cubic);

     // Distribute these elastic moduli onto this tensor.
     elastic_field.distribute_moduli (elastic_moduli);


Author:

Toby D. Young 2009, 2010, 2012.

---

Constructor & Destructor Documentation

template<int dim, int rank, typename ValueType = double>

ewalena::Crystal::CrystalFieldBase< dim, rank, ValueType >::CrystalFieldBase	(	const Vector< ValueType > &	moduli = Vector<ValueType> (),
		const SymmetryFlag &	symmetry_flags = SymmetryFlag::null,
		const SymmetryFlag &	group_flags = SymmetryFlag::null
	)		[inline]

Constructor.

template<int dim, int rank, typename ValueType = double>

virtual ewalena::Crystal::CrystalFieldBase< dim, rank, ValueType >::~CrystalFieldBase

(

)

[virtual]

Virtual destructor.

---

Member Function Documentation

template<int dim, int rank, typename ValueType = double>

virtual void ewalena::Crystal::CrystalFieldBase< dim, rank, ValueType >::assign_moduli

(

const Vector< ValueType > &

moduli

)

[protected, virtual]

Assign moduli to this tensor field. Any previously assigned moduli will be brutely overwritten.

template<int dim, int rank, typename ValueType = double>

virtual void ewalena::Crystal::CrystalFieldBase< dim, rank, ValueType >::assign_symmetry_flags	(	const SymmetryFlag &	symmetry_flags,
		const SymmetryFlag &	group_flags = null
	)		[virtual]

Assign symmetry flags to this tensor field. Any previously assigned symmetry flags will be brutely overwritten.

template<int dim, int rank, typename ValueType = double>

virtual void ewalena::Crystal::CrystalFieldBase< dim, rank, ValueType >::distribute_moduli

(

const Vector< ValueType > &

moduli

)

[virtual]

Distribute moduli onto this tensor field according to rules governing the crystal group symmetry.

Reimplemented in ewalena::Crystal::ElasticField< ValueType >, ewalena::Crystal::DielectricField< ValueType >, ewalena::Crystal::PiezoelectricField< ValueType >, ewalena::Crystal::PyroelectricField< ValueType >, and ewalena::Crystal::FerroelectricField< ValueType >.

template<int dim, int rank, typename ValueType = double>

SymmetryFlag ewalena::Crystal::CrystalFieldBase< dim, rank, ValueType >::group_flags

(

)

const

Return the symmetry flag associated with this tensor field.

template<int dim, int rank, typename ValueType = double>

unsigned int ewalena::Crystal::CrystalFieldBase< dim, rank, ValueType >::n_components

(

)

const

Return the number of components in this tensor field.

Reimplemented from ewalena::Tensor< dim, rank, ValueType >.

template<int dim, int rank, typename ValueType = double>

Tensor<dim, rank, ValueType> ewalena::Crystal::CrystalFieldBase< dim, rank, ValueType >::operator*

(

)

const [inline]

Access operator to the underlying tensor associated with this tensor field.

Reimplemented from ewalena::Tensor< dim, rank, ValueType >.

Reimplemented in ewalena::Crystal::ElasticField< ValueType >, ewalena::Crystal::DielectricField< ValueType >, ewalena::Crystal::PiezoelectricField< ValueType >, ewalena::Crystal::PyroelectricField< ValueType >, and ewalena::Crystal::FerroelectricField< ValueType >.

template<int dim, int rank, typename ValueType = double>

CrystalFieldBase<dim, rank, ValueType>& ewalena::Crystal::CrystalFieldBase< dim, rank, ValueType >::operator=

(

const CrystalFieldBase< dim, rank, ValueType > &

T

)

Assignment operator. Initialise this tensor with the T.

template<int dim, int rank, typename ValueType = double>

SymmetryFlag ewalena::Crystal::CrystalFieldBase< dim, rank, ValueType >::symmetry_flags

(

)

const

Return the symmetry flag associated with this tensor field.

template<int dim, int rank, typename ValueType = double>

void ewalena::Crystal::CrystalFieldBase< dim, rank, ValueType >::write_gnuplot

(

std::ostream &

out

)

const

Write gnuplot.

---

Member Data Documentation

template<int dim, int rank, typename ValueType = double>

SymmetryFlag ewalena::Crystal::CrystalFieldBase< dim, rank, ValueType >::group_flags_ [protected]

Original symmetry flags handed to the constructor.

template<int dim, int rank, typename ValueType = double>

Vector<ValueType> ewalena::Crystal::CrystalFieldBase< dim, rank, ValueType >::moduli_ [protected]

Original moduli handed to the constructor.

template<int dim, int rank, typename ValueType = double>

SymmetryFlag ewalena::Crystal::CrystalFieldBase< dim, rank, ValueType >::symmetry_flags_ [protected]

Original symmetry flags handed to the constructor.

---

The documentation for this class was generated from the following file:

• include/ewalena/numerics/crystal_field_base.h
